BASIC ELECTRONICS & ANALOG LAB EQUIPMENTS :
| SL. NO. | NAME OF THE MACHINES/EQUIPMENTS/TOOLS | SPECIFICATION | |
| 1 | Screw Driver | 200mm, 150mm, 100mm | |
| 2 | Combination Plier | ||
| 3 | Hand drill | ||
| 4 | Ball pin Hammer | ||
| 5 | Wire stipper | ||
| 6 | Nose Plier | ||
| 7 | Spanner | ||
| 8 | Multi purpose Knife | ||
| 9 | Side cutting Plier | ||
| 10 | Poker | ||
| 11 | Pincer | ||
| 12 | Dot Pinch | ||
| 13 | Ginlet | ||
| 14 | Centre punch | ||
| 15 | Flat File | ||
| 16 | Round File | ||
| 17 | CRO | 30 MHz, 50 MHz | |
| 18 | Digital Storage CRO | 25 MHz | |
| 19 | Half &full control | 1-phase bridge rectifier | |
| 20 | Function Generator | 1 MHz | |
| 21 | I.C Trainer Kit | ||
| 22 | Digital Gauge Meter | ||
| 23 | Power Supply Unit | 12V D.C. | |
| 24 | Basic Electronics & Power Electronic | Trainer Kit | |
| 25 | Soldering Iron | ||
| 26 | P-A System | 250 | |
| 27 | Transister characteristics kit | CB,CE,CC | |
| 28 | Common emmiter Amplifier kit | ||
| 29 | R-C Coupled amplifier kit | ||
| 30 | Push-Pull Amp.Kit | ||
| 31 | Power Amp. Kit | Class-A,B,C,AB | |
| 32 | Multivibrator Kit | Astable,Bistable,Monostable | |
| 33 | Oscillator | Hartly,Colpits,Phase Shift,Wein Bridge | |
| 34 | MOSFET Kit | ||
| 35 | JFET kit | ||
| 36 | Transuster Biasing Kit | ||
| 37 | Rectifier Kit | HWR.FWR | |
| 38 | Zener Diode Voltage Regulator Kit | ||
| 39 | Diode Characteristics Kit | ||
| 40 | Multimeter | Digital, Analog | |
| 41 |
| ||
| 42 | Solder | ||
| 43 | Flux | ||
| 44 | Diode | ||
| 45 | Transformer | 500mA | |
| 46 | 1A |
LECTURER
B.TECH (ELECTRICAL ENGINEERING)
LECTURER
B.TECH. (ELECT. ENGG.)
TEACHING ASST
DIPLOMA IN ELECT. ENGG.
LECTURER
B. TECH (ETC ENGG.)
